Varuna RCC Water Tank

About Varuna RCC Water Tank

Varuna RCC Water Tank

            A RCC (Reinforced Cement Concrete) water tank used for fish farming (also known as a fish culture tank) in a vertical configuration is a cylindrical or rectangular upright tank designed to hold and rear fish in a controlled aquaculture environment. Here's a detailed vertical description of such a tank from bottom to top:

Vertical Description of RCC Water Tank

1. Foundation/Base Slab:

   • Constructed with reinforced concrete (typically M20 to M30 grade).

   • Thickness: 150300 mm depending on the size and capacity.

   • May include waterproofing additives.

   • Slight slope towards the drain outlet to assist in cleaning and water flow.

2. Drain Outlet:

   • Located at the bottom center or side of the tank.

   • Fitted with PVC or stainless-steel piping and a valve.

   • Allows for easy water exchange and removal of sludge or waste.

3. Tank Walls (Vertical Structure):

   • Made of RCC with vertical reinforcement bars and horizontal stirrups.

   • Thickness: 100200 mm depending on tank diameter/height.

   • Interior is often plastered and finished with food-grade waterproofing or epoxy coating.

   • Circular tanks are preferred for water circulation and fish movement.

4. Inlet Pipe:

   • Positioned 150300 mm below the top rim.

   • Connected to a water source (borewell, reservoir, filtration system).

   • May include flow control valves and aeration fittings.

5. Overflow Pipe:

   • Located just below the rim to prevent flooding.

   • Ensures excess water exits safely.

6. Aeration System (Optional):

   • Air stones or diffusers placed near the tank bottom.

   • Connected to air pumps or blowers for oxygenation.

7. Tank Covering (Optional):

   • May include a mesh or net cover to prevent fish from jumping out and to protect from predators.

   • Sometimes a shed or shade is installed above to control sunlight and temperature.

8. Access Ladder/Platform:

   • Provided if the tank height is more than 1.2 meters.

   • Ensures safe inspection and maintenance.
